UNHCR Standard
Waterproof, tear-proof and material trim finish
90x180cm/1.62m2
Will last for +12 months of use under hard tropical conditions
Suitable for one adult or two children.
All items are packed onto EPAL Euro pallets (800mm x 1,200mm) to a maximum height of 1500mm, unless requested otherwise.
Features:
- Will last for +12 months of use under hard tropical conditions
- Waterproof, tearproof and material trim finish
- Suitable for one adult and two child
- All specified testing must have been independently completed and passed for each proposed Compliance reports.
- The two short sides to be secured with a first stitch folded hem of the mat, plus one bias 40mm binding tape of minimum 10g/m with stitches through the fabric of the mat, OR with a double folded stitched hem. Four sides trim finished. The binding is secured and durable to prevent the fraying of the mat, which will result in rapid disintegration of the structure
Technical Specifications
The mats should be from 100% synthetic yarns from virgin or recycle raw material. Recycle raw materials would be preferable for ecological onsiderations. Synthetic sleeping mats that are made from recycle materials must not contain fillers, like calcium carbonate or any other.
The synthetic yarns in a tightly woven 2/2 twill structure, using a monofilament or multifilament warp and thick tape PP or polyester yarn in weft. The end widths are to be secured with a woven, bias-binding tape with stitches, through the fabric of the mat.
Sleeping mat size: 1.8 x 0.9 meters.
Sleeping mat area: 1.62m2.
Weight: 0.500 Kg / m2 Minimum +/- 5 %.
Color: Assorted colors.
- Material
Marking, logo and color are customized to your requirements.
Mat | 100% synthetic yarn virgin or recycled raw material |
Yarn | Tightly woven 2/2 twill structure using a mono-filament or multi-filament warp and thick tape PP or polyester yarn in weft |
End width | Secured with a woven, bias-binding tape with stitches through the mat fabric |
Content per bale | 25 pcs |
Bale dimension | 92 x 75 x 25 cm |
Bale volume | 0.1744 cbm approx. |
Bale weight | 21.50 kg |
Bale per pallet | 4 bales (4 x 25 = 100 pieces) |
Weight per pallet | 100 kg approx. |
Dimension per pallet | 112 x 78 x 114 cm |
Volume per pallet | 0.9959 cbm approx. |
